The product is to service at such control circuit as AC50~60Hz, voltage of 380VAC or 220VDC and current of 10A to automatically control machine tool, limit movement and action of drive mechanism and control program.
The nominal service conditions include an ambient temperature of -25℃+40℃, an ambient relative humidity of 90%, and altitude of 2000m and protection degree of IP65. It complies with the standard of IEC337-1 and GB14048.5-2001.
|
ltem
|
QXCK-J model double insulation, according to CENELEC EN50041
|
|
|
Metal head
direcacting
type
|
Metal stell-roller
directacting
type
|
Metal thermoplastic
roller tumbler
directacting type
|
Adjustable length and
thermoplastic roller
tumbler type
|
Metal thermoplastic
cylindrical tumbler type
Diameter=6mm
length=200mm
|
Thermoplastic roller
tumbler directacting
type, Single direction
with horizontal movement
|
Multidirection
type
|
|
Machime life(million times)
|
30
|
25
|
30
|
30
|
30
|
15
|
30
|
|
Motion speed(m/s)
|
0.5
|
1
|
1.5
|
1.5
|
1.5
|
1
|
1.5
|
|
Protection degree
|
IP65
|
|
Rated work charcters
|
ALTIPAK AC 15; A 300(UE=240V, LE=3A)ALTIVAR DC13;Q 300(UE=250V, LE=0.27A)
|
|
Boundary dimensions: width×depth×heigh
|
41×41×77
|
|
Complete switch(2 poles 1 -close+1- ope,quick)
|
QXCK-J161
QXCK-J1161
|
QXCK-J167
|
QXCK-J10511
QXCK-J10531
|
QXCK-J10541
QXCK-J139
|
QXCK-J10559
|
QXCK-J121
|
QXCK-J108
|
