Models

QZ-3101

QZ-3102

QZ-3103

QZ-3104(3108)

OF(Max.)

1200gf(11.77N)

1200gf(11.77N)

1200gf(11.77N)

580gf(5.69N)

RF(Min.)

450gf(4.41N)

450gf(4.41N)

450gf(4.41N)

150gf(1.47N)

PT(Max.)

1.8mm

1.8mm

1.8mm

25

OT(Min.)

3mm

3mm

3mm

40

MD(Max.)

0.2mm

0.2mm

0.2mm

3

OP

15.7±1mm

28.5±1mm

28.5±1mm

-

Models

QZ-3110

QZ-3111

QZ-3112

QZ-3113

QZ-3169

OF(Max.)

1200gf(11.77N)

1800gf(17.65N)

1800gf(17.65N)

1800gf(17.65N)

150gf(1.47N)

RF(Min.)

450gf(4.41N)

450gf(4.41N)

450gf(4.41N)

450gf(4.41N)

-

PT(Max.)

1.8mm

1.8mm

1.8mm

1.8mm

15°

OT(Min.)

3mm

3mm

3mm

3mm

-

MD(Max.)

0.2mm

0.2mm

0.2mm

0.2mm

-

OP

28.5±1mm

24.9±1mm

34.3±1mm

34.3±1mm

-

Ratings

Noninductive Load (A)

Inductive Load (A)

Rated voltage

Resistance Load

Lamp Load

Inductive Load

Motor Load

NC

NO

NC

NO

NC

NO

NC

NO

125 VAC

250 VAC

5 (0.1)

3

1.5

1

0.7

0.5

3

2

1.3

0.8

8 VDC

14 VDC

30 VDC

125 VDC

250 VDC

5 (0.1)

5 (0.1)

4 (0.1)

0.4

0.2

2

2

2

0.05

0.03

5

4

3

0.4

0.2

5

4

3

0.4

0.2

3

3

3

0.05

0.03
