Performance parameters
|
|
Project
|
Classification
|
5A、3A/125，250VAC
|
|
Allow the operating speed
|
0.1mm ~ 1m / sec (button type)
|
|
Allows switching frequency
|
Mechanical 400 times / min Electrical 30 times / min
|
|
Insulation resistance
|
100M Ω or more (by DC500V insulation resistance detected)
|
|
Contact resistance
|
Within the initial 30mΩ
|
|
Resistant to breakdown voltage
|
Non-connected terminals
|
AC1000V 50/60Hz 1minute
|
|
Among non-live metal parts and each terminal
|
AC1500V 50/60Hz 1minute
|
|
Between the ground and each terminal
|
|
Vibration resistance
|
Malfunction
|
Double amplitude 1.5mm 10 ~ 50Hz
|
|
Impact
|
Durable
|
1000m/s
|
|
Malfunction
|
300m/s
|
|
Life
|
Electrical life (resistive load)
|
More than 100,000 times
|
|
Mechanical life (predetermined overtravel)
|
More than 10,000,000
|
|
Ambient temperature, humidity
|
-25 ~ + 80 ℃ (no icing), 35% ~ 85% RH
|
