Characteristics Of Contact Module
|
|
Items
|
QV-21 QV-16 QV-11
|
|
Permissible make-break frequency
|
0.1mm-1m/s (pushbutton type)
|
|
Misoperation
|
Double-amplitude 1.5mm 10-5Hz (contacts separate in less than 1ms)
|
|
Permissible make-break frequency
|
OF 0.49N type: 98m/s2 below; OF 1.96N type, 3.92N type: 294m/s2 below; OF 0.98N type: 196m/s2 below (contacts separate in less than 1ms)
|
|
Mechanical life (stipulated over travel OT)
|
10,000,000 times above (make-break frequency is 60 times/min)
|
|
Ambient temperature and humidity
|
-25℃~+80℃ (no icing or dew), 85%RH below (at about +5~35℃)
|
|
Weight (kg)
|
About 6.2g (pushbutton type)
|
